Color del Chasis

Prodcut NameFlexx HDFlexx HD
Seat Width* Seat Depth20/22/24*16/18/2020/22/24*16/18/20
Caster Size* Rear Wheel Size6/7/8*14F/14Q/22Q/24Q6/7/8*14F/14Q/22Q/24Q
Seat Width (cm)51/56/6151/56/61
Seat Depth(cm)41/46/5141/46/51
Seat Height(cm)46~5346~53
Backrest Height(cm)43、51、38~4643、51、38~46
Armrest Height(cm)21~2921~29
Calf Length(cm)38~4838~48
Backrest Angle(X°)(-4)~16(-4)~16
Seat Angle (X°)3~73~7
Max. User Weight (kg)170170
Weight W/O Accessories (kg)Min. 10.6Min. 10.9
Total Weight (kg)Min. 16.5 (14F)
Min. 17 (24Q)
Min. 16.8 (14F)
Min. 17.3 (24Q)
Overall L x W x H (cm)Min. 108*71*84
Max. 118*81*104
Min. 108*71*84
Max. 118*81*104
Overall Collapsed L x W x H (cm)Collapsed Width = 35Collapsed Width = 35

Remark : Karma reserves the right to modify information herein without further notice.
